Motherboard Installation
Page 13
“Auto Jumper Yes” Guide
• To enable the “Auto Jumper Yes”, the onboard jumper JP16 must shorted (1-2). Then,
the CPU brands and its core voltage will automatically detected. But one thing to remind
is the CPU speed is necessary to select a suitable one at the CMOS setup. Or, if JP16 is
shorted (2-3), that means you should follow the jumper table (at the next page) to setup
your CPU settings manually. On the other hand, pressing the key “F” to clear the
CMOS setting and “J” to re-detect the CPU setting during power up your system.
“CPU Voltage Selection”
• The voltage regulator will automatically detect and switch between Single Power Plane
& Dual Power Planes.
