Zida TX98-3D - Page 9

Motherboard Installation
Page 6
3.3V Key
Unbuffered
DRAM Key
128 Bit 168 PIN DRAM DIMM
Push to remove
DIMM module
Push to remove
DIMM module
1
2
Vertically Insert
for Installation
168-Pin SDRAM Module Installation Diagram
CAUTION
SDRAM Module cannot be used together with the SIMMs Module.
