ZIEHL SPI1021 User Manual

SPI1021 12570-0701-07 Page
4
/ 24 www.ziehl.de
10
sealable button + LED
Press for > 2 s
Lock / Unlock
LED red
Settings and simulation mode are locked,
While attempting to set, 8LOc 8 is displayed for 3s
LED green
Setting and simulation enabled
11
LEDs frequency / voltage / VSR Limit value undercut / exceeded (red)
ON, 8AL 8or 8AL M8
Limit value undercut / exceeded
FLASHES, 8AL 8or 8AL M8
Reset delay 8dof 8 counting down
2 Default settings and firmware version
When changing programs, all parameters are reset to the *default settings.
Menu
item
Parameter / Unit
Default setting
Users
data
CEI 0-21
DEWA
3AC+N
230V
3AC
400V
1AC+N
230V
3AC+N
230V
3AC
400V
3AC
100V
Pr1
Pr2
Pr3 *
Pr4
Pr5
Pr6
U,,
59.S2
59>S2
u,, Alarm on/off
Off
Off
Off
Off
Off
OFF
u,, Overvoltage
V
264
458
264
264
458
115
H,, Hysteresis
V
10.5
17.5
10.5
10.5
17.5
4.5
dal Response time
s
0.10
0.10
0.10
0.10
0.10
0.10
dof OFF-delay
s
0
0
0
0
0
0
U,
59.S1
59>S1
u, Alarm on/off
On
On
On
On
On
On
u, Overvoltage
V
264
458
264
253
438
120
H, Hysteresis
V
10.5
17.5
10.5
10.5
17.5
4.3
dal Response time
s
0.20
0.20
0.20
0.20
0.20
0.60
dof OFF-delay
s
0
0
0
0
0
0
UM
59-Av
UM Alarm on/off
On
On
On
On
On
On
UM Overvoltage
V
253
438
253
253
438
110
HM Hysteresis
V
10.0
17.5
10.0
10.0
17.5
4.3
dal Response time
s
3.00
3.00
3.00
3.00
3.00
3.00
dof OFF-delay
s
0
0
0
0
0
0
U_
27.S1
27<S1
u_ Alarm on/off
On
On
On
On
On
On
u_ Undervoltage
V
196
339
196
196
339
85
H_ Hysteresis
V
8.0
13.5
8.0
8.0
13.5
3.5
dal Response time
s
0.40
0.40
0.40
0.40
0.40
1.50
dof OFF-delay
s
0
0
0
0
0
0
U__
27.S2
27<S2
u__ Alarm on/off
On
On
On
On
On
On
u__ Undervoltage
V
92
159
92
92
159
3.0
H__ Hysteresis
V
3.7
3.7
3.7
3.7
6.4
1.5
dal Response time
s
0.20
0.20
0.20
0.20
0.20
0.20
dof OFF-delay
s
0
0
0
0
0
0
F,,
81.S2
81>S2
F,, Alarm on/off
On
On
On
On
On
On
F,, Overfrequency
Hz
51.50
51.50
51.50
54.00
54.00
54.00
H,, Hysteresis
Hz
0.10
0.10
0.10
0.10
0.10
0.10
dal Response time
s
0.10
0.10
0.10
10.0
10.0
10.0
dof OFF-delay
s
0
0
0
0
0
0
F,
81.S1
81>S1
F, Alarm on/off
On
Off
Off
Off
Off
Off
F, Overfrequency
Hz
50.50
50.50
50.50
52.50
52.50
52.50
H, Hysteresis
Hz
0.10
0.10
0.10
0.10
0.10
0.10
dal Response time
s
10.00
0.10
0.10
0.10
0.10
0.10
dof OFF-delay
s
0
0
0
0
0
0
