TS5000A Tripod Turnstile User Manual
Page | 16 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Figure 5-1
Attention: The maintenance of the above-mentioned tripod turnstile must be maintained by professional
personnel. Especially the movement and the electric control part, first cut off the power supply, ensure the
operation safety.
Keyhole
Uplift the lib
Chassis
Glass
Fixing screw
Upper lid
