TS5000A Tripod Turnstile
User Manual
Page | 7 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Figure 1-1
Technical Specifications 1.3
Input Voltage
AC 100~120V /200~240V,
50Hz /60Hz
Max. Tolerance of Arms
Center: 80 kg
End: 40 kg
Rated Power 60 W Drive Mode Motorized
Operating
Environment
Indoor and Outdoor
(shelter)
Arm Length (mm) 500
Operating
Temperature
-28ºC ~ 60ºC Net Weight 60kg
Operating Humidity
5% ~ 80% Gross Weight 90kg
Flow Rate Max 30 passages / minute Dimension(mm) Figure 1
L = 1200, W = 300, H =
1010
Input Control Signal
Dry contact Package Size (mm) L =1330 , W =420 , H =1110
Table 1-2
