SECTION 3 – QUICK RELEASE CASSETTE SYSTEM
The G2™ has a Long-Life Diaphragm and a Quick Release System. This unique feature allows almost
instantaneous access to the Diaphragm.
Large foreign objects, such as children’s toys, tree branches and rocks, should be removed manually from your
pool prior to operating an automatic pool cleaner. In the even of blockage occuring the Quick Release Casette
System allows you the opportunity to remove the blockage or check the Diaphragm for damage in seconds at
the poolside.
The Quick Release Cassette System also allows you to reset the Diaphragm which may also resolve performing
problems such as running and stopping coverage problems and/or your G2™ not climbing the pool walls.
STEP 1: Procedure to Remove Diaphragm.
Hold the G2™ with one hand and unscrew the Cassette Swivel nut +/- 3 turns anti-clockwise (Diagram 7).
Pull the Cassette System from the G2™ body (Diagram 8).
Diagram 8
Diagram 7
7
