SECTION 3 – QUICK RELEASE CASSETTE SYSTEM
Pull the Inner Extension Pipe with Diaphragm through the Cassette Body (Diagram 13).
Diagram 13
STEP 5: Resetting the Diaphragm
If the gap of the Diaphragm is excessive (more than 5 mm), yet the Diaphragm is not torn or damaged, it can be
reset by leaving one ridge of the Diaphragm exposed from the Cassette Body (Diagram 14). This may resolve
performance-related problems such as running and stopping, coverage problems and/or your G2™ not
climbing walls.
Hold the Cassette and tighten the Extension Pipe by turning clockwise (Diagram 15). Do not over-tighten.
Diagram 14
10
