Zodiac G2 - SECTION 1 - INSTALLATION; Preparing your pool and filtration system; Assembling your G2

STEP 1: Preparing your pool and ltration system
IMPORTANT
The ltration system must be operating at its maximum water ow before you install your G2™, otherwise you will
have to re-adjust it after cleaning the pool lter.
Installation is easy if you follow these simple preliminary steps:
1. Empty the weir basket.
2. Clean the pump basket.
3. Backwash the lter until the sight glass is clear.
4. Adjust all return jets (whether your pool has one, two or more) to point downwards and towards each other so that
you DO NOT see a circular water ow or ripples on the surface of your pool.
STEP 2: Assembling your G2™
Fitting the Quick Release Cassette System
Hold the G2™ with one hand and t the Quick Release Cassette System as shown on the Diagram
1. Tighten the Cassette Swivel Nut by turning it +/- 3 turns clockwise.
SECTION 1 - INSTALLATION
DIAGRAM 1
Fitting Quick ReleaseCassette System
Cassette
Swivel Nut
Fitting the Deector Wheel
Every G2™ Pool Cleaner is supplied with
a Deector Wheel. The purpose of this
wheel is to protect the Outer Extension
Pipe, outside housing and also to guid the
G2™ away from swimming pool steps or
stairs. Position the Deector Wheel on
the Outer Extension Pipe as in Diagram
2, making sure that at the top clips are
seated in the groove. Ensure that the
Deector Wheel rotates freely.
DIAGRAM 2
Fitting the Deector Wheel
2
