Zoom H1essential User Manual

Recording
Monitoring input sounds
Use headphones, for example, to monitor input sounds and adjust the volume.
1. Connect headphones, for example, to the PHONE/LINE OUT jack.
2. Use to adjust the volume.
The volume is shown on the display while the volume is being adjusted.
NOTE
• When nothing is connected to the PHONE/LINE OUT jack, operating will change the
speaker volume.
• The built-in speaker cannot be used for monitoring while recording.
• When “Volume Control” is set to “Fixed”, cannot be used to adjust the volume. To use
for volume adjustment, set “Volume Control” to “Knob”. (→ Making output settings)
HINT
When monitoring with headphones is unnecessary, disconnecting headphones from the PHONE/LINE OUT
jack can increase the amount of operation time when using batteries.
38

Zoom H1essential Specifications

General

Maximum Sound Pressure Level	120 dB SPL
Recording Format	WAV
Bit Depth	24-bit
Sampling Rate	44.1 kHz, 48 kHz, 96 kHz
Microphone Type	Condenser
Recording Media	microSD, microSDHC
Power	USB
Battery Life	Approx. 10 hours
Frequency Response	20 Hz - 20 kHz
Storage	microSD, microSDHC
