Zoom H1essential User Manual

Muting the USB mic
When the USB mic function is being used, the mic sound can be temporarily muted so audio is not sent to
the computer, smartphone or tablet.
1. Press when the Home Screen is open and the USB mic function is in use.
The MUTE window will open and output to the computer, smartphone or tablet will be muted.
2. Press when muted.
This ends muting and returns to the previous screen.
NOTE
This mutes the input sound, so recorded sound and monitoring sound output from the PHONE/LINE OUT
jack will be muted in the same way.
76

Zoom H1essential Specifications

General

Maximum Sound Pressure Level	120 dB SPL
Recording Format	WAV
Bit Depth	24-bit
Sampling Rate	44.1 kHz, 48 kHz, 96 kHz
Microphone Type	Condenser
Recording Media	microSD, microSDHC
Power	USB
Battery Life	Approx. 10 hours
Frequency Response	20 Hz - 20 kHz
Storage	microSD, microSDHC
