Zoom H1essential User Manual

Volume raised
Resolution is high
Clipping advantage
If a waveform sounds clipped when output from the H1essential or in a DAW, it can be edited after
recording to lower its volume and restore an unclipped waveform because the data in the 32-bit float WAV
file itself is not clipped.
■ 16/24-bit WAV
Clipped recording Still clipped
Volume lowered
■ 32-bit float WAV
Clipped recording Not clipped
Volume lowered
6

Zoom H1essential Specifications

General

Maximum Sound Pressure Level	120 dB SPL
Recording Format	WAV
Bit Depth	24-bit
Sampling Rate	44.1 kHz, 48 kHz, 96 kHz
Microphone Type	Condenser
Recording Media	microSD, microSDHC
Power	USB
Battery Life	Approx. 10 hours
Frequency Response	20 Hz - 20 kHz
Storage	microSD, microSDHC
