Zoom H1essential User Manual

Reducing noise (Lo Cut)
When using the USB mic function, low frequencies from the built-in XY mic can be cut to reduce the sound
of wind and pop noises, for example.
1. Press on the Home Screen (when connected with the USB mic function) repeatedly to select the
cutoff frequency.
The selected frequency is shown on the Home Screen.
LO CUT can be set to OFF, 80 Hz, 160 Hz or 240 Hz.
79

Zoom H1essential Specifications

General

Maximum Sound Pressure Level	120 dB SPL
Recording Format	WAV
Bit Depth	24-bit
Sampling Rate	44.1 kHz, 48 kHz, 96 kHz
Microphone Type	Condenser
Recording Media	microSD, microSDHC
Power	USB
Battery Life	Approx. 10 hours
Frequency Response	20 Hz - 20 kHz
Storage	microSD, microSDHC
