30
Specifications
Specifications
Effect types 55 types
Maximum number of
simultaneous effects
6
Number of patch memories
50
Sampling frequency 44.1kHz
A/D conversion 24-bit with 128x oversampling
D/A conversion 24-bit with 128x oversampling
Signal processing 32-bit floating point & 32-bit fixed point
Frequency characteristics 20-20kHz (+1dB/3dB) (10kΩ load)
Display LCD
Input Standard monaural phone jack
Rated input level: 20dBm, Input impedance 1MΩ
Output Standard monaural phone jack
Maximum output level: Line +5dBm (with output load impedance of 10 kΩ or more)
Power
AC adapter
DC9V (center minus plug), 500 mA (ZOOM AD-16)
Batteries
About 7 hours of continuous operation using AA alkaline batteries
USB
Dimensions 130.3mm(D) x 77.5mm(W) x 58.5mm(H)
USB Firmware update
Weight 350g
0dBm
0.775Vrms
