Zoom V3 User Manual

11
Button Explanation Adjustment
VOCODER**
This creates a vocoder sound effect.
This corrects the pitch to the set key.*
Pitch correction amount and
octave setting
PITCH
CORRECT
KEY**
This corrects the pitch to the set key.* This can
be adjusted from a gentle pitch correction to a
mechanical effect that changes the pitch in steps.
Pitch correction amount
OCTAVE This doubles the voice one octave down/up.
Balances original and effect
sounds
UNISON
This creates an effect like singing the same part
twice by duplicating the sound with the pitch and
timing slightly shifted.
Effect mix level
WHISTLE
This has the effect of sounding like whistling
even when just singing.
Amount of original sound in
mix/whistle octave
PITCH
CORRECT
CHROMATIC**
This corrects the pitch to semitones.
This can be adjusted from a gentle pitch
correction to a mechanical effect that changes the
pitch in steps. We recommend this setting when
a song is in an unknown key or it has numerous
key changes.
Pitch correction amount
DISTORTION This distorts the voice heavily. Distortion amount
TELEPHONE This emulates a retro-sounding telephone. Frequency band affected
BEAT BOX This adds impact for beat boxing. Boost amount
CHORUS This chorus is full and gentle. Effect mix level
DEEP
This makes the voice low-pitched and deep by
lowering the pitch and changing the character
greatly.
Voice character
ROBOT** This makes the voice sound robotic. Pitch of the robot voice sound
CHILD
This makes the voice high-pitched and childlike
by raising the pitch and changing the character
greatly.
Voice character
FORMANT
CHARACTER
This changes the character of the voice without
changing the pitch.
Voice character
The original voice is restored
when the EFFECT ADJUST knob
is at its center position.
*
For details about setting the key, see step 1 of “Setting the HARMONY key and pitches” on page 12.
**This follows the standard pitch setting (“Making unit settings” on page 14).
HINT
If an expression pedal (ZOOM FP02M) is connected, it can be used to adjust the effect (same as using
). If a footswitch (ZOOM FS01) is connected, it can be used to turn the selected effect off.

Zoom V3 Specifications

Power

AC adapter voltage	9V DC
AC adapter current	500 mA
phantom power	+48 V
battery type	4 AA batteries
battery life	3.5 hours

Inputs and Outputs

MIC IN input gain	+3 – 40 dB
MIC IN maximum input level	+4 dBu
MIC IN input impedance	3 kΩ or more
AUX IN rated input level	−10 dBu
AUX IN input impedance	22 kΩ
L/R output maximum level	+6 dBu
L/R output impedance	100 Ω
PHONES maximum output	20 mW + 20 mW (into 32 Ω load)

Audio Specifications

sampling frequency	44.1 kHz
A/D conversion	24-bit 128× oversampling
D/A conversion	24-bit 128× oversampling
signal processing	32-bit
frequency response	20 Hz – 20 kHz (+1 dB/−3 dB)

Weight and Dimensions

weight	0.59 kg
depth	150 mm
width	190 mm
height	50 mm
