Page #16 background image
Z2I-3982-01
ZOOM CORPORATION
4-4-3 Kanda-surugadai, Chiyoda-ku, Tokyo 101-0062 Japan
www.zoom.co.jp
Specications
Simultaneous effects 5 types (compressor, enhance, selectable effect, delay, and reverb)
Selectable effects 16 types (HARMONY, VOCODER, TALK BOX, PITCH CORRECT-KEY, OCTAVE,
UNISON, WHISTLE, PITCH CORRECT-CHROMATIC, DISTORTION, TELEPHONE,
BEAT BOX, CHORUS, CHILD, ROBOT, DEEP, FORMANT CHARACTER)
Sampling frequency 44.1 kHz
A/D conversion 24-bit 128× oversampling
D/A conversion 24-bit 128× oversampling
Signal processing 32-bit
Frequency response 20 Hz – 20 kHz (+1 dB/−3 dB) (10 kΩ load)
Inputs MIC IN XLR jack
Input gain: +3 – 40 dB
Maximum input level: +4 dBu
Input impedance: 3 kΩ or more
Phantom power: +48 V
AUX IN Stereo mini jack
Rated input level: −10 dBu
Input impedance (line): 22 kΩ
Outputs L/R Standard mono phone jack
Maximum output level: +6 dBu
Output impedance: 100 Ω
PHONES Stereo mini jack
Maximum output: 20 mW + 20 mW (into 32 Ω load)
Equivalent input noise
(when
phantom power off)
−125 dBu or less (A-weighted, 150 Ω input, +40 dB input gain)
Control input FS01/FP02M input
Power AC adapter: 9V DC 500 mA center negative (ZOOM AD-16)
4 AA batteries (about 3.5 hours continuous operation time when using
alkaline batteries)
USB Port and supported cable type: USB 2.0 Micro-B
Audio interface: USB 2.0 Full Speed, 44.1 kHz, 16/24/32-bit, 2 in, 2 out
• Use a USB cable that supports data transfer.
• Power can also be supplied through the USB port.
• When using a cable designed only for power, other USB functions cannot
be used.
External dimensions 150 mm (D) × 190 mm (W) × 50 mm (H)
Weight 0.59 kg (excluding batteries)
Note: 0 dBu = 0.775 V
