Edition 2 Chapter 1 Page 1-41
Feb/2013 Maintenance and Service
Put thin steel wire or ethylene plastic strap on the end of the wire-rope.
(i) Install the new wire-rope onto the main winch drum with the chock.
1 Tools necessary: Hammer.
Figure 1-31 New Wire-Rope on the Drum
• Make sure that the chock is in the correct position before you make the
wire-rope tight.
• Make sure that the end of the wire-rope does not go fully through the drum.
The wire-rope must extend more than the surface of the drum.
(j) Spool-up the wire-rope.
1 Tools necessary: Thin steel wire or ethylene plastic strap.
Figure 1-32 Monitor the Rope (Must Lay Flat and Evenly)
To Next Page
