Configuration
02060220.fm 11.12.07/Ch,Kx Network T8 Control Unit – Version 2.0 2 - 27
Have all the configuration tasks described in Section 2.1 Necessary operating sys-
tem settings (Windows) been performed?
D TCP/IP installed?
D Different IP addresses issued to all network users?
D Same subnet mask used?
D Different computer names entered?
D Microsoft Network Client installed?
D Share-level access control enabled in Windows 95/98/ME?
Additional tips if using BNC connections
Are the BNC cabling and connectors correct?
D Have BNC T adapters with terminating resistors been used on the up-
link switch and LCD/TFT/MPC control unit network components?
Are the BNC cables defective?
D Measure the continuity of the cables' core and shield
D Test for absence of a short circuit in the cable between the core and
shield
Is the resistance of the terminating resistors 50 Ohm, or are they defective?
D Measure the resistance with a multimeter
Is the connected cable type compatible with the PC network card?
D Automatic detection of media type or correct setting for media type
Is operating system Windows 95 or later installed for TFT/MPC control unit?
