45
4. Installing Your Device
Installing the Device on a Wall
1. Mark the positions for drilling holes on the wall.
2. Firstly, use a 6mm percussion drill to drill holes at the marked positions, and
install four M6 expansion spigots. Secondly, use four M6 expansion bolts to x
the bracket to the wall.
CAUTION:
The screw hole of the bracket faces upwards. Do not install the bracket upside
down. Otherwise, the screw cannot be installed later.
