CommandFunction
zte(cfg)#setl2pt<protocol-list>{enable|disable|invalid}
EnablesordisablesL2pttransparent
transmissionfunction.
showl2pt(allcongurationmodes)
DisplaysthecongurationofL2pt
transparenttransmission.
Layer2ProtocolTransparentTransmissionCongurationInstance
lCongurationDescription
AsshowninFigure4-17,settheLACPtransparenttransmissionfunctionofL2ptof
Switch1toimplementthelinkaggregationbetweenSwitch2andSwitch3.The
congurationincreasesthelinkbandwidthandrealizestheredundantbackup.
Figure4-17Layer2ProtocolTransparentTransmissionCongurationTopology
lCongurationProcedure
zte(cfg)#setlacpenable
zte(cfg)#setlacpaggregator1addport1,2
zte(cfg)#setl2pt0x02enable
zte(cfg)#setvlan100enable
zte(cfg)#setvlan100addport1,3
zte(cfg)#setport1,3pvid100
zte(cfg)#setvlan200enable
zte(cfg)#setvlan200addport2,4
zte(cfg)#setport2,4pvid200
lCongurationVerication
DisplaytheaggregationstateofSwitch2andSwitch3:
zte(cfg)#showlacpaggregator1
Group1
ActorPartner
4-60
