ZXR102900ESeriesCongurationGuide
Figure4-9MSTPTopologicalStructure
SpanningTreeProtocol(STP)cancalculateaccordingtotheprotocol.Portsaredivided
intodifferentparts:
lMaster:TheporttypeisintroducedinMSTPprotocol.Whenthemultipledifferent
areasexist,themainportistheminimalpathcostportpointtotheroot.
lRoot:Theportthathastheminimalcosttorootbridgeandtakeschargeinforwarding
datatorootnode.Whenmultipleportshavethesamecosttotherootbridge,then
theportwiththelowestportprioritybecomestotherootport.
lDesignated:Theporttransmitsdatatoswitchdownward,andsendsSTPprotocol
messagetomaintainthestateofSTP .
lBackup:TheportreceivestheSTPmessage,whichprovesthatthereexitsaloop
routetotheportitself.
lAlternate:TheportreceivesexcessSTPprotocolmessagefromotherequipment.
However,whentheoriginallinkabnormallylost,theportunderthisstatecantransfer
totransmittingstateandmaintainthenetworkinsteadoftheportlapsed.
lEdged:Theportisusedtoconnecttheterminalequipment,suchasPC.Theport
doesnotparticipateincalculationbeforeSTPisstable,andthestatecanbeswitched
fast.
Accordingtoportrole,thestateafterthecalculationbeingsteadyisshowninT able4-1.
Table4-1PortRoleandPortState
PortrolePortstate
MasterForward
RootForward
DesignatedForward
4-34
