MultiAreaIS-ISv6Configuration
Example
Thisexampledescribeshowtoconguremultiple-areaIS-ISv6.
Forlargesizenetwork,multiple-areanetworkshallbeconsidered
touseinIS-ISv6.Setthenearrouterstobeinoneareaaccording
totheirpositionsandfunctionsbecauseareadivisionishelpful
todecreasethedemandformemory,androutersonlyneedto
maintainsmallerlinkstatedatabase.
AsshowninFigure4,R1isinArea1,R2,R3,andR4inArea0,
andR5andR6inArea2.OnR1,performrouteaggregationto
networksegmentsinarea1.Thestaticroutesareredistributedto
theIS-ISv6onR6.
FIGURE4IS-ISV6MULTIPLE-AREACONFIGURATIONEXAMPLE
R1conguration:
ZXR10_R1(config)#routerisis
ZXR10_R1(config-router)#area01
ZXR10_R1(config-router)#system-id00D0.D0C7.53E0
ZXR10_R1(config-router)#is-typeLEVEL-1-2
ZXR10_R1(config-router)#exit
ZXR10_R1(config)#interfacefei_2/4
ZXR10_R1(config-if)#ipv6enable
ZXR10_R1(config-if)#ipv6address2009::1/64
ZXR10_R1(config-if)#ipv6routerisis
ZXR10_R1(config-if)#isiscircuit-typeLEVEL-2
ZXR10_R1(config-if)#exit
ZXR10_R1(config)#interfacefei_2/6
ZXR10_R1(config-if)#ipv6enable
ZXR10_R1(config-if)#ipv6address2001:1::1/64
ZXR10_R1(config-if)#ipv6routerisis
ZXR10_R1(config-if)#isiscircuit-typeLEVEL-1
ZXR10_R1(config-if)#exit
ZXR10_R1(config)#interfacefei_2/7
ZXR10_R1(config-if)#ipv6enable
ZXR10_R1(config-if)#ipv6address2001:2::1/64
ZXR10_R1(config-if)#ipv6routerisis
ZXR10_R1(config-if)#isiscircuit-typeLEVEL-1
ZXR10_R1(config-if)#exit
