Chapter9IPv6TunnelConguration
ConfiguringIPv6Tunnel
MaintenanceandDiagnosis
TomaintainanddiagnoseIPv6tunnel,usethefollowingcom-
mands.
CommandFunction
ZXR10#showipv6interface<interface-name>Thisshowstunnelinterface
information.
ZXR10#debugtunnelpacket
Thisshowstheinformationof
sentandreceivedpackets.
Result:ThemaintenanceanddiagnosisofIPv6tunnelhasbeen
congured.
IPv6TunnelConfiguration
Example
ThisexampledescribeshowtocongureIPv6tunnel.
AsshowninFigure8,supposethatR1andR2aredualstack
routers,andPC1andPC2areIPv6hosts.CongureIPv6address
is4000::1,andgatewayis4000:128inPC1.CongureIPv6ad-
dressis5000::1,andgatewayis5000:128inPC2.
ThecongurationofR1andR2isshownbelow.RIPngprotocolis
notnecessary.Staticrouteorotherroutingprotocolsalsocanbe
used.
FIGURE8IPV6TUNNELCONFIGURATIONEXAMPLE
R1conguration:
