Table 17 - Analog Header Pin Out
Two pins required. Dedicated
pins on the 7 series package.
This is the dedicated analog
input channel for the ADC(s).
1V peak-to-
peak input
maximum
XADC-VN-R : M12
XADC-VP-R : L11
Two pins required. Auxiliary
analog input channel 0. Two
dedicated channels needed for
simultaneous sampling
applications. Should also
support use as IO inputs by
disconnection of anti-alias cap
see
1V peak-to-
peak input
maximum
XADC-AD0N-R : E16
XADC-AD0P-R : F16
Two pins required. Auxiliary
analog input channel 8. Two
dedicated channels needed for
simultaneous sampling
applications. Should also
support use as IO inputs by
disconnection of anti-alias cap
see
1V peak-to-
peak input
maximum
XADC-AD8N-R : D17
XADC-AD8P-R : D16
Two pins required. Access to
thermal Diode
XADC-DXN : N12
XADC-DXP : N11
Three pins required. Analog
ground reference GNDADC.
Analog channel isolation
One pin. This is the analog 1.8V
supply for XADC.
One pin. This is the 1.25V
reference from the board.
1.25V ±0.2%
50ppm/ºC
@5mA max
Filtered 5V supply from board.
G0: 18
G1: 17
G2: 20
G3: 19
Adjustable Voltage, set by J18
