Zynq ZedBoard User Manual

1-Aug-2012
32
 Tolerance
o 1.0V Vccint  0.95 to 1.05V
o Vccaux  +/- 5%
o Vcco  +/-5%
 Ramp time
o 0.20 to 50ms
o In-rush current must be controlled so the power circuitry is not overloaded at
start-up
 Monotonicity
o No negative dips in Vccint or Vccaux power-up ramps
 Sequencing
o Verify sequencing responds as expected based on design
 Refer to Zynq Datasheet for the latest requirements
2.11.8 Probes
Two ground test point are available on the board, J3 and J4. This allows easy access to attach
ground leads of two scope probes to the board without having to locate GND pins on a header.

Zynq ZedBoard Specifications

General

Processor	Dual-core ARM Cortex-A9
Clock Speed	667 MHz
System Memory	512 MB DDR3
Flash Memory	256 MB
Video Output	HDMI, VGA
Storage	SD Card Slot
FPGA	Xilinx Zynq-7000 XC7Z020
Ethernet	10/100/1000 Mbps Ethernet
USB	USB 2.0 (OTG and Host)
Audio	3.5mm jack, HDMI
Expansion Connectors	FMC, Pmod
Power	5V DC
