Chapter 7 Connection Status
AX/DX/EX/PX Series User’s Guide
140
Figure 74 Guest WiFi Settings: Configuration
To assign different SSIDs to the 2.4 GHz and 5 GHz guest wireless networks, clear the Keep 2.4G and 5G
the same check box in the WiFi Settings screen, and the Guest WiFi Settings screen will change.
Figure 75 Guest WiFi Settings: Different SSIDs
Each field is described in the following table.
Table 26 WiFi Settings: Configuration
LABEL DESCRIPTION
2.4G/5G WiFi Click this switch to enable or disable the 2.4 GHz and/or 5 GHz wireless networks. When the
switch goes to the right , the function is enabled. Otherwise, it is not.
WiFi Name The SSID (Service Set IDentity) identifies the service set with which a wireless device is
associated. Wireless devices associating to the access point (AP) must have the same SSID.
Enter a descriptive name (up to 32 English keyboard characters) for the wireless LAN.
WiFi Password If you selected Random Password, this field displays a pre-shared key generated by the Zyxel
Device.
If you did not select Random Password, you can manually type a pre-shared key from 8 to 64
case-sensitive keyboard characters.
Click the Eye icon to show or hide the password of your wireless network. When the Eye icon
is slashed , you will see the password in plain text. Otherwise, it is hidden.
