2N IP series Automation Manual

2N TELEKOMUNIKACE a.s., www.2n.cz 19/104
DtmfEntered
The block defines the event that is generated by entering of a DTMF DtmfEntered
numeric code confirmed with the * key in an incoming or outgoing call.
Input parameters
Code – define the numeric code.
Valid values:
numeric code – 12345, e.g.
Output parameters
Event – the Event invoke connected Event or Action.
Code – the detected received numeric code which was the last to generate this
event.
Example
Event generated upon detection of DTMF code 12345*
