3-22
n Figure 3-40 Configure the AAA accounting method for the ISP domai
Perform the following configuration, as shown in Figure 3-40.
z Select the domain name system.
z Select the Accounting Optional checkbox and then select Enable.
z Select the Default Accounting checkbox and then select RADIUS as the accounting mode.
z Select system from the Name drop-down list to use it as the accounting scheme.
z Click Apply. A configuration progress dialog box appears.
z After the configuration process is complete, click Close.
4) Configure wireless service
# Create a wireless service.
Select Wireless Service > Access Service from the navigation tree, and click New to enter the page
for creating a wireless service, as shown in
Figure 3-41:
Figure 3-41 Create a wireless service
z Set the service name as dot1x.
z Select the wireless service type crypto.
z Click Apply.
5) Configure 802.1X authentication
After you create a wireless service, you will enter the wireless service configuration page. Then you can
configure 802.1X authentication on the Security Setup area, as shown in
Figure 3-42:
