4-6 CHAPTER 4: PERFORMING TROUBLESHOOTING AND DIAGNOSTIC TESTS
3 Start the diagnostic program on the echo server.
The diagnostic program that you use depends on the
adapter that is installed in the echo server. After the system
prompt of the drive containing the Configuration and
Diagnostic Program, enter the name of the appropriate
program (for example, 3C523) from Table 4-1.
4 In the Configuration and Diagnostic Program main window,
select Echo Server from the Test menu on the menu bar.
The program notifies you that your computer is now set up
as an echo server.
Starting the Group 3 Test
To run the Group 3 test on a 3C590 PCI adapter, follow these
steps:
1 Start the Configuration and Diagnostic Program.
This program must be on the computer containing the
adapter you want to test.
2 Select Test Setup from the Test menu.
3 Enable the Group 3 test. Highlight <OK> and press [Enter].
4 Go to the Run Tests dialog box to start the tests.
Table 4-1 Diagnostic Programs
Diagnostic
Program Name
Adapter in the Echo Server
3C503.EXE EtherLink II

or II TP, EtherLink II/16 or II/16 TP
3C505.EXE EtherLink Plus

3C507.EXE EtherLink 16 or EtherLink 16 TP
3C5X9CFG.EXE EtherLink III family
3C523.EXE EtherLink/MC
3C523TP.EXE EtherLink/MC TP
3C527.EXE EtherLink/MC 32
3C59XCFG.EXE 3C590 PCI
