A-4 APPENDIX A: SOFTWARE OPTION SETTINGS
7 Select Configuration and Diagnostic Program from the
next screen.
8 Do one of the following:
■ If you have a single adapter installed, the menu selection
Configure Adapter appears already highlighted. Press
[Enter].
■ If you have multiple adapters installed, use the arrow keys
to select an adapter, as shown in Figure A-2. Press [Enter].
Figure A-2 Main Window with Multiple Adapters
9 When a screen identifying the adapter appears with the
Configure Adapter menu item highlighted, press [Enter].
10 Press [Shift]+[Tab] to highlight the first option in the
main dialog box, and use the arrow keys to highlight the
parameter you want to change.
Figure A-3 is an example of the adapter configuration dialog
box, showing both the automatically set configuration values,
which you cannot change (I/O Port Address and Interrupt
Request Level), and the default software option settings,
which you can change.
Initial Adapter Selection
Select Quit
Select the adapter to be configured and/or tested.
[ENTER]=<Select>
[Alt]+<Highlighted Key>=Execute Function [
↑↓
]=Scroll
[TAB]=Next Field [SHIFT+TAB]=Previous Field [F1]=Help [ESC]=<Quit>
Installed Adapters
3Com 3C590-TP PCI Dev/Slot 12: Node Address = 00608C001358
3Com 3C590-COMBO PCI Dev/Slot 13: Node Address = 00608C001368
InstallQuit View Select F1=HelpTest
EtherDisk for 3C59X Fast EtherLink/EtherLink III Bus Master Adapters v.X.X
(C) Copyright 1995, 3Com Corporation. All Rights Reserved
To Next Page
Loading...
