46
Adjustments (continued)
Taping Head Adjustments – Refer to Manual 2
TAPE WEB ALIGNMENT – Manual 2
TAPE DRUM FRICTION BRAKE – Manual 2
APPLYING MECHANISM SPRING – Manual 2I
ONE-WAY TENSION ROLLER – Manual 2
TAPE LEG LENGTH ADJUSTMENT – Manual 2
EXTENDED PLATE BUMPER - Manual 2
Figure 13-9 – Box Drive Belt Tension Adjustment, Upper Belts (Infeed End)
• To reduce the risk associated with sharp blade hazards:
− Keep hands and fi ngers away from tape cutoff blades under orange blade guards.
The blades are extremely sharp
WARNING
700rks
2010 January
Belt Tension
Screw, M8
Hex Head
Infeed End
13mm Box Wrench
M10 Lock Nut
Front Cover
M5 x 10 Screw (4)
• To reduce the risk associated with mechanical and electrical hazards:
− Turn electrical and air supply off and disconnect before performing any adjustments, maintenance
or servicing the machine or taping heads
WARNING
• To reduce the risk associated with mechanical and electrical hazards:
− Turn electrical and air supply off and disconnect before performing any adjustments, maintenance
or servicing the machine or taping heads
WARNING
