Indications
• Polymerization of light-curing dental materials with
photo initiator for the wavelength range 430
-
480 nm.
-
Most light-curing dental materials
respond to this
light wavelength range. In case of doubt, please
contact the respective manufacturer.
Contraindications
Do not use Elipar DeepCure-S in patients with a
history of photobiological reactions (including
individuals with urticaria solaris or erythropoietic proto-
porphyria) or who are currently on photo sensitizing
medication (including 8-methoxypsoralen or
dimethylchlorotetracycline).
Potential Undesirable Side Effects and Complica-
tions
Heat generation can result in pulp or tissue damage.
Unprotected light exposure can result in eye damage.
Refer to section “Safety” for correct handling.
Technical Data
Charger
Operating voltage: 100
-
127 V 50/60 Hz
230 V 50/60 Hz (see rating
plate for factory-set voltage)
Power input: 0.08 A (230 V)
0.16 A (100
-
127 V)
Dimensions: Length: 170 mm
Width: 95 mm
Height: 50 mm
Weight: 650 g
Classification: Protection class II,
Handpiece
Power supply: lithium-ion battery,
nominal voltage 3.7 V
Utilizable wavelength
range: 430
-
480 nm
Wavelength peak: 444
-
452 nm
Light intensity (between
400 and 515 nm): 1470 mW/cm
2
-
10%/+20%
(independent of battery power
level)
device in accordance with IEC 60601-1 and is available
as a tabletop device. Wall mounting is not possible.
In comparison with conventional light-curing devices,
Elipar DeepCure-S features excellent beam collimation
and a uniform beam profile, directing more of the light
energy to the restoration being polymerized and
producing a deep, uniform, and complete curing of the
restoration.
The light source is a high-performance light diode
(LED). The beam emerging from the device covers the
light wavelength range of 430 to 480 nm relevant, for
instance, for camphor quinone products and is suitable
for use with the majority of light-curing dental materials,
including materials for fillings, liners, core build-ups,
fissure sealings, temporary restorations, and cements
for indirect restorations.
See the manufacturer’s information for the exposure
time required for the specific dental material.
Settable exposure times:
• 5, 10, 15, 20 sec
• Continuous mode (120 sec)
• Tack-cure mode (1 sec)
The charger is equipped with an integrated light
intensity meter for the Elipar DeepCure-S.
The unit is shipped with a light guide with 10 mm
diameter. It is not permissible to use the light guides of
other units.
The handpiece is equipped with a sleep mode to
minimize the unit’s energy consumption. The hand -
piece switches to sleep mode once it is placed in the
charger or if left unused for approx. 5 minutes outside
the charger.
+
These Instructions for Use should be kept for the
duration of product use. The product may only be
used when the product labeling is clearly read-
able. For details on all additionally mentioned
products please refer to the corresponding In-
structions for Use.
Intended Purpose
Intended purpose: curing light for light curing dental
materials.
Intended users: educated dental professionals who
have theoretical and practical knowledge on usage of
dental products.
Patient target group: all patients requiring dental treat-
ment, unless the patient’s condition limits the use.
Clinical benefit: initiates the curing reaction of light cur-
ing dental materials.
