7. Adjustment and Setting
Warning
・Do not open Main body cover and Terminal box cover with its power turned on.
Always check that there is no explosive gas or vapor in that location to remove the
cover (Main body cover or Terminal Box cover) of Fame-proof enclosure with the power
on.
* Button Cover is not Flame-proof enclosure.
・Opening button cover and operating buttons with its power turned on
not open the Main body cover.
・Be sure never to cause mechanical sparks with tools.
・When using Flame-proof equipment at hazardous areas, always wiring in accordance
with 『ANNEX1 Instructions about Flame-proof type Equipment』.
ＥＳＣ
Operating Button
Button Cover
LCD
Main body cover
