3S MP 100 - Characteristics

17
7-3-4-5 Characteristics
Set characteristics
○ Sequence
①Unlock
LOCK ⏎ LK? ▼ ULK? ⏎
②Operation
MANU ⏎ SPLT ▼ CHAR ⏎ SEL ⏎ LIN? ⏎ : Choose linear characteristics
▼ EQ? ⏎ : Choose near Eq% characteristics
▼ QO? ⏎ : Choose 'quick open' characteristics
▼ USR? ⏎ : Choose user characteristics
▼ USR? ⏎ ***.** % ⏎ : Customize user characteristics
Input signal [%]
Target
position[%]
Actuator
direction DA
Actuator
direction RA
LIN
EQ
(1/50)
QO
(1/75)
POS1
100
0
0
0
0
POS2
93.75
6.25
6.25
0.55
25.26
POS3
87.5
12.5
12.5
1.26
44.21
POS4
81.25
18.75
18.75
2.16
58.41
POS5
75
25
25
3.32
69.01
POS6
68.75
31.25
31.25
4.79
77.06
POS7
62.5
37.5
37.5
6.67
83.05
POS8
56.25
43.75
43.75
9.07
87.54
POS9
50
50
50
12.14
90.91
POS10
43.75
56.25
56.25
16.06
93.44
POS11
37.5
62.5
62.5
21.06
95.33
POS12
31.25
68.75
68.75
27.45
96.75
POS13
25
75
75
35.61
97.82
POS14
18.75
81.25
81.25
46.02
98.61
POS15
12.5
87.5
87.5
59.32
99.21
POS16
6.25
93.75
93.75
76.3
99.66
POS17
0
100
100
100
100
○ Notice
・Refer to 7-3-5-4 Direction D / R.
・The default setting is LIN（Linear）
・You can customize 17 kinds of user Characteristics
(Push ⏎ button to confirm each setting)
The interval of input signal is fixed. (6.25%)
