7-3 Menu description
Operation
・Use four buttons ▲, ▼, ⏎, ESC
・Press the ⏎ button to complete the operation
・Press the ESC button to cancel the operation
・Input signal should be kept to a minimum 4mA
・After finishing operation, press ESC button to get back to the operating mode
(It would not be switched automatically)
7-3-1 Lock/Unlock
Enable/Disable to change settings.
When locked, the key mark will light up.
○Sequence
Unlock
LOCK ⏎ LK? ▼ ULK? ⏎
Lock
LOCK ⏎ ULK? ▼ LK? ⏎
○Notice
・After completing setup, lock the setting function to prevent misoperation.
・Before you start operations, set to unlock
・When the input signal is shut with this status unlocked, it will be locked when the signal
recovered.
7-3-2 Switching display
Switch display mode
○ Sequence
DISP ⏎ SIG? mA ⏎ : Show Input signal (mA)
▼ SIG? % ⏎ : Show input signal (％)
▼ POS? mA ⏎ : Show position signal (mA)
▼ POS? % ⏎ : Show position signal (%)
▼ TMP? ℃ ⏎ : Show internal temperature℃（℉）
○Notice
・SIG or POS is displayed to indicate input signal or position signal.
・The default setting is SIG mA
・Switching display is available while the device is locked
・Ambient temperature would be displayed using ℃ or ℉ which you have chosen
