3S MP 100 - Diagnostic of Sensor

21
7-3-5-1-2 Diagnostic of Sensor
Diagnose Sensor and set partial stroke
○ Sequence
①Unlock
LOCK ⏎ LK? ▼ ULK? ⏎
②Operation
MANU ⏎ SPLT ▼ SUB ⏎ DIAG ⏎ INPU ▼ FB
[Alarm Set]
⏎ ALRM ⏎ MIN ⏎ ***.* ％ ⏎ : Set lower limit
▼ MAX ⏎ ***.* ％ ⏎ : Set upper limit
[Change direction times]
▼ CYCL ⏎ TOTL ⏎ **** (k) : Show changing direction times after
shipping
▼ WDTH ⏎ **.* ％ ⏎ : Set the minimum travel counted as
changing direction
▼ TERM ⏎ ALRM ⏎ **** k ⏎ : Set alarm for changing direction times
▼ DATA ⏎ **** k : Show changing direction times after
setting
▼ CLR ⏎ CLR? ⏎ : Clear changing direction times after
setting
[Travel distance]
▼ DIST ⏎ TOTL ⏎ **** (k)m : Show travel distance after shipping
▼ TERM ⏎ ALRM ⏎ **** km ⏎ : Set alarm for the travel distance
▼ RESL ⏎ **** mm ⏎ : Set the resolution for sensing the travel
▼ STRK ⏎ **** mm ⏎ : Set actuator stroke
▼ DATA ⏎ **** km : Display the travel distance after setting
▼ CLR ⏎ CLR? ⏎ : Clear the travel distance after setting
[Partial stroke test]
▼ PST ⏎ ITVL ⏎ **** H ⏎ : Set the interval time
▼ WDTH ⏎ ***.* ％ ⏎ : Set carried out stroke span
▼ DURA ⏎ **** s ⏎ : Set duration
○ Notice
・The default setting for alarm is OFF
・Change direction times after shipping and travel distance after shipping cannot be cleared.
・The default setting for partial stroke is OFF
・If the shut off or the full open of the valve is working, partial stroke test is not performed
・When it changes the interval time of the partial stroke test, immediately once, partial stroke
test is performed. Please make sure there is no problem in setting.
