3S MP 100 - SUB Menu: Diagnostics and Information

20
7-3-5 SUB
Describe SUB menu below. (diagnostic function, position transmitter function, device information)
7-3-5-1 Diagnostic function
Describe diagnostic function
7-3-5-1-1 Calibration & Diagnostic of input signal
Adjust calibration and diagnose of input signal
○ Sequence
①Unlock
LOCK ⏎ LK? ▼ ULK? ⏎
②Operation
MANU ⏎ SPLT ▼ SUB ⏎ DIAG ⏎ INPU ⏎ PROF
[Calibrate input signal]
⏎ CO4 mA ⏎ 4? mA ⏎ : calibrate figure for 4mA
▼ CO20 mA ⏎ 20? mA ⏎ : calibrate figure for 20mA
[Alarm set]
▼ ALRM ⏎ MIN ⏎ *.** mA ⏎ : Set the alarm (Min)
▼ MAX ⏎ **.** mA ⏎ : Set the alarm (Max)
[Shut down Count]
▼ SHUT ⏎ VIEW ⏎ **** : Show Shut down times
▼ CLR ⏎ CLR? ⏎ : Delete records
[Total uptime record]
▼ TIME ⏎ TOTL ⏎ **** H(D) : Show total uptime
▼ TERM ⏎ ALRM ⏎ **** D ⏎ : Set limit total uptime
▼ DATA ⏎ **** H(D) : Show running hours from the first setting
▼ CLR ⏎ CLR? ⏎ : Delete records
○ Notice
・The default setting is OFF
・Initializing of total uptime record is not allowed
