7-3-3 Auto-tuning
ALL : Start Auto-tuning for all setting
A-1 : Start Zero-span and operation direction setting
A-2 : Adjust torque motor setting
A-3 : Adjust PID constant and input signal filter
○ Sequence
①Unlock
LOCK ⏎ LK? ▼ ULK? ⏎
②Tuning
TUNE ⏎ ALL? ⏎ ---＞ DONE : Full tuning
▼ A-1? ⏎ ---＞ DONE : A-1 Tuning
▼ A-2? ⏎ ---＞ DONE : A-2 Tuning
▼ A-3? ⏎ ---＞ DONE : A-3 Tuning
○ Notice
・Do not touch the moving parts during tuning is in progress.
・Input signal should be kept to a minimum 4mA while operating.
・After the Auto-tuning is complete, DONE is shown on the display
・By the actuator, there is a case the proper dynamic characteristics can not be obtained.You can
also go into manual mode and set the dynamic characteristics. Please refer to the 7-3-4-3 PID.
・Recommend to perform full Auto tuning first, after you have installed device
・【Important】Operate below three configuration before operate auto tuning
7-3-4-6 Actuator
7-3-4-7 Single / Double action
7-3-4-8 Direction of rotation
7-3-4 Manual-tuning
Configure manually
7-3-4-1 Split range
Set split range
○ Sequence
①Unlock
LOCK ⏎ LK? ▼ ULK? ⏎
②Operation
MANU ⏎ SPLT ⏎ ZERO ⏎ **.** mA ⏎ : Set input signal 0% with ▼▲ buttons
▼ SPAN ⏎ **.** mA ⏎ : Set input signal 100% with ▼▲ buttons
○ Notice
・The signal difference between 0 % and 100 % needs to be 4.00 mA or more.
・The signal corresponds to 0％ shall be 4.00 mA or more.
・The signal corresponds to 100％ shall be 20.00 mA or below.
・The default value is 0%＝4.00mA, 100%＝20.00mA
To Next Page
