USER’S MANUAL
No.
Code
Name
Quantity
Remark
1
TPF4-100-00A(B)
Column jointing(L,R)
2
1 each
2
TPF4-100-10-05
Pulley
6
3
GB894.1-86
Spindle spring washer
6
d25
4
TPF4-100-12GM
Cover
2
5
GB819-85
Cross bolt
4
M6X10
6
GB5781-86
Hexangular bolt C
8
M12X40
7
GB6170-86
Nut
8
M12
8
GB97.2-85
Flat washer
8
d12
9
GB93-87
Spring washer
8
d12
10
TPF4-100-13-01
Up board
2
Jointing parts
11
Bush
6
DU-SF-1 2510
12
GB95-85
Flat washer C
2
d24
13
GB894.2-86
A spindle spring washer
2
d25
13.1
TPF4B-600G
Protective board
1
13.2
GB70-85
Inner hexangular bolt
4
M12X20
13.3
GB97.2-85
Flat washer
4
d12
14
TPF4-200-11-01
Rack spindle
4
15
GB91-86
Shaft sheath
4
16
GB97.2-85
Flat washer A
4
d10
17
TPF4-200-11-02
Spring
4
18
TPF4-200-11-04
Rack board
4
19
TPF4-200-11-05
Ramp board
4
20
GB6170-86
Nut
4
M10
21
GB97.2-85
Flat washer
4
d10
22
GB93-87
Spring washer
4
d10
23
Ball handle
4
24
TPF4-400-07
Bolt
8
25
TPF4-400-01
Rubber washer
4
Rubber
26
TPF4-400-02-00
Salver jointing
4
Jointing parts
27
TPF4-400-03
Adapter
4
28
GB41-86
Nut
8
M8
29
TPF4-400-05-00M
Swing arms
2
Jointing parts
30
TPF4-400-06-00
Pin jointing
4
Jointing parts
31
GB819-85
Cross bolt
4
M8X16
32
TPF4-400-04-00
Salver jointing
2
Jointing parts
33
TPF4-400-05K-00A(B)M
Swing arms (L,R)
1 each
Jointing parts
34
GB5781-86
Hexangular bolt C
4
M8X15
35
GB6170-86
Nut
4
M8
36
GB97.2-85
Flat washer
4
d8
-25-
