AA4C AA-2PFP45 - Page 29

USER’S MANUAL
No.
Code
Name
Quantity
Remark
37
GB93-87
Spring washer
4
d8
38
Hydraulic pump
1
39
TPF4-500-08
Washer
1
40
TPF4-500-07
Hydraulic connection
1
41
TPF4-500-05
Elbow fitting
1
42
TPF4-500-12
Hose
1
L=1650
43
TPF4-500-06
Elbow fitting
1
44
TPF4-500-02
Direct outside fitting
1
45
TPF4-500-10
Hose
1
L=2850
45.1
TPF4-500-03
Direct outside fitting
2
46
TPF4-200-01-00
Carriage jointing
2
Jointing parts
47
TPF4A-200-12
Nylon block
16
Nylon1010
48
GB91-86
Shaft sheath
2
2.5X32
49
GB97.2-85
Flat washer
2
d20
50
TPF4-300-00
arrester jointing
2
51
TPF4-300-02
Pull spring
2
52
GB70-85
Inner hexangular bolt
2
M6X30
53
TPF4-300-09
Spring
2
54
TPF4-300-05-01
Pull rope
2
55
TPF4-300-05-02
Sheath pose
4
59
TPF4-500-01
Hydraulic cylinder
2
60
TPF4-100-14-02
Spindle
2
61
TPF4-100-14-01
Idler wheel
2
62
GB8942-86
Spindle spring washer
2
d25
63
Spindle
4
DU-SF-1 2520
64
TPF4-800
Chain
2
65
TPF4-900
Steel cable
1
66
TPF4-900
Steel cable
1
67
Nut
8
