AAON RN Series Installation, Operation & Maintanance Manual

14
RN Series Feature String Nomenclature
:
SIZE
VLT
CONFIG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
16
17
18
19
20
21
22
23
R
N
–
0 2 5
– 3
–
0 –
B
B
0 2
– 3 8 4 :
A
0 0 0
–
D
0
B
–
D
E
H
–
0
B
A
–
0
D
0 0 0 0
L
–
0 0
–
0 0
B
0 0 0 0 0
B
GEN
Model Options
Unit Feature Options
Model Option A: COOLING/HEAT
PUMP
0 = Standard
A3: COIL COATING
1 = Polymer E-Coated Evap. and Cond.
2 = Stainless Steel Casing Evap and Cond
8 = Polymer E-Coated Cond.
9 = Polymer E-Coated Cooling Coil
A = Stainless Steel Evap. Coil Casing + Polymer E-
Coated Cond. Coil
B = Stainless Steel Casing Cond & Polymer E-
Coated Cooling Coil
C = Stainless Steel Casing Cond. Only
D = Stainless Steel Cooling Coil Casing
0 = No Cooling
A4: COOLING/HEAT PUMP STAGING
1 = 1 Stage
2 = 2 Stage
4 = 4 Stage
9 = Modulating - Lead VCC
A = Modulating - All VCC
B = 1 Stage + 1 Stage Auxiliary Heat
C = 2 Stage + 1 Stage Auxiliary Heat
D = 4 Stage + 1 Stage Auxiliary Heat
E = Modulating - Lead VCC + 1 Stage Aux. Heat
F = Modulating - All VCC + 1 Stage Aux. Heat
H = Single Serpentine 8 fpi
J = Half Serpentine 8 fpi
K = Single Serpentine 10 fpi
L = Half Serpentine 10 fpi
M = Single Serpentine 12 fpi
N = Half Serpentine 12 fpi
P = 1 Stage + 2 Stage Auxiliary Heat
Q = 2 Stage + 2 Stage Auxiliary Heat
R = 4 Stage + 2 Stage Auxiliary Heat
S = Modulating - Lead VCC + 2 Stage Aux. Heat
T = Modulating - All VCC + 2 Stage Aux. Heat
U = 1 Stage + 4 Stage Auxiliary Heat
V = 2 Stage + 4 Stage Auxiliary Heat
W = 4 Stage + 4 Stage Auxiliary Heat
Y = Modulating - Lead VCC + 4 Stage Aux. Heat
Z = Modulating - All VCC + 4 Stage Aux. Heat
Model Option B: HEATING
0 = No Heating
B1: HEATING TYPE
1 = Electric Heat
2 = Natural Gas Aluminized
3 = Natural Gas Stainless Steel
4 = High Altitude Natural Gas Aluminized
5 = High Altitude Natural Gas Stainless Steel
6 = LP Gas Aluminized
7 = LP Gas Stainless Steel
8 = High Altitude LP Gas Aluminized
9 = High Altitude LP Gas Stainless Steel
C = Steam Distributing Standard
D = Steam Distributing Polymer E-Coated
E = Hot Water Standard
F = Hot Water Polymer E-Coated

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
