AAON RN Series Installation, Operation & Maintanance Manual

96
Table 34 - 50, 60, and 70 ton Pre Filters
Feature 6A
Quantity / Size
Type
0
No Pre Filters
A
24 / 12” x 24” x 2”
Pleated, 30% Eff, MERV 8
B
6 / 16” x 25” x 1”
Metal Mesh, Outside Air
with PE or PR, Feature 1A = B, C
4 / 16” x 25” x 1”
C
12 / 47” x 12” x 5/16”
Lint Screen
Table 35 - 55, 65, and 75 ton Pre Filters
Feature
Quantity / Size Type
6A
6B
0
A,B,C,F,G,H
No Pre Filters
A A,B,C,F,G,H
15 / 20” x 24” x 2” &
5 / 16” x 20” x 2”
Pleated, 30% Eff, MERV 8
B A,B,C,F,G,H 56 / 20” x 20” x 1” Metal Mesh, Outside Air
C A,C
8 / 40” x 18” &
8 / 20” x 18”
Lint Screen
C B,F,G,H
1 / 60” x 16” &
3 / 60” x 24” &
1 / 40” x 16” &
3 / 40” x 24”
Table 36 - 90-140 ton Pre Filters
Feature
Quantity / Size Type
6A
6B
0
A,B,C,F,G,H
No Pre Filters
A A,B,C,F,G,H
21 / 20” x 24” x 2” &
7 / 16” x 20” x 2”
Pleated, 30% Eff, MERV 8
B A,B,C,F,G,H 56 / 20” x 20” x 1” Metal Mesh, Outside Air
C A,C
11 / 20” x 18” &
12 / 40” x 18”
Lint Screen
C B,F,G,H
2 / 40” x 16” &
6 / 40” x 24” &
1 / 60” x 16” &
3 / 60” x 24”

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
