AAON RN Series Installation, Operation & Maintanance Manual

39
Duct Connection
Note: If outside air will be in contact with
the air tunnel base of an A, B or C cabinet
unit (6-25 and 30 tons), the unit should
include the base insulation option or the
base must be field insulated. D and E
cabinet (26 and 31-140 tons) units include
base insulation standard.
Figure 14 - Duct Connection
Do not drill or punch holes in the
base of the unit, from inside the unit
or from below the unit to attach
ductwork. Leaking may occur if unit
base is punctured.
CAUTION

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
