AAON RN Series Installation, Operation & Maintanance Manual

16
RN Series Feature String Nomenclature
:
SIZE
VLT
CONFIG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
16
17
18
19
20
21
22
23
R
N
–
0 2 5
–
3
– 0
–
B
B
0 2
– 3 8 4 :
A
0 0 0 –
D
0
B
–
D
E
H
– 0
B
A
– 0
D
0 0 0 0
L
–
0 0
– 0 0
B
0 0 0 0 0
B
GEN
Model Options
Unit Feature Options
Feature 1: RETURN/OUTSIDE AIR
0 = Standard – None
1B: RETURN/EXHAUST AIR BLOWER
CONFIGURATION
A = 1 Blower + Standard Eff. Motor
C = 1 Blower + Premium Eff. Motor
D = 2 Blowers + Premium Eff. Motors
E = 1 Blower + Premium Eff. + 1 VFD
F = 2 Blowers + Premium Eff. + 1 VFD
G = 2 Blowers + Premium Eff. + 2 VFDs
0 = Standard - None
1C: RETURN/EXHAUST AIR BLOWER
A = 12”x9” Forward Curved
B = 15” Backward Curved Plenum
C = 18.5” Backward Curved Plenum
D = 22” Backward Curved Plenum
F = 27” Backward Curved Plenum
G = 22” Direct Drive Axial Flow
H = 35.5” Direct Drive Axial Flow
J = 15” BC Plenum - 50% Width with Banding
K = 18.5” BC Plenum - 70% Width with Banding
L = 22” BC Plenum - 70% Width with Banding
M = 27” BC Plenum - 70% Width with Banding
N = 30” Backward Curved Plenum
P = 42” 9 Blade Direct Drive Axial Flow
Q = 42” 12 Blade Direct Drive Axial Flow
R = 24” Backward Curved Plenum
S = 33” Backward Curved Plenum
0 = Standard - None
1D: RETURN/EXHAUST AIR BLOWER
MOTOR
C = 1 hp - 1760 rpm
D = 2 hp - 1760 rpm
E = 3 hp - 1760 rpm
F = 5 hp - 1760 rpm
G = 7.5 hp - 1760 rpm
H = 10 hp - 1760 rpm
L = 15 hp - 1760 rpm
M = 20 hp - 1760 rpm
N = 1 hp - 1170 rpm
P = 2 hp - 1170 rpm
Q = 3 hp - 1170 rpm
R = 5 hp - 1170 rpm
S = 7.5 hp - 1170 rpm
T = 10 hp - 1170 rpm
U = 15 hp - 1170 rpm
V = 20 hp - 1170 rpm
W = 25 hp - 1170 rpm
Y = 30 hp - 1170 rpm
3 = 25 hp - 1760 rpm
4 = 30 hp - 1760 rpm
5 = 40 hp - 1760 rpm
6 = 50 hp - 1760 rpm

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
