AAON RN Series Installation, Operation & Maintanance Manual

22
RN Series Feature String Nomenclature
:
SIZE
VLT
CONFIG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
16
17
18
19
20
21
22
23
R
N
–
0 2 5
–
3
– 0
–
B
B
0 2
– 3 8 4 :
A
0 0 0 –
D
0
B
–
D
E
H
– 0
B
A
– 0
D
0 0 0 0
L
–
0 0
– 0 0
B
0 0 0 0 0
B
GEN
Model Options
Unit Feature Options
0 = Standard - ETL U.S.A. Listing
Feature 19: CODE OPTIONS
B = Chicago - Cool + Gas
C = Chicago - Cool + Electric Heat
D = Chicago - Cool Only
E = Chicago - Gas Only
F = Chicago - Electric Heat Only
G = Chicago - No Cool + No Heat
H = ETL U.S.A. + Canada Listing
K = California OSHPD Certification
L = Shake Table Cert. (ASCE 7-05/ICC-ES AC 156)
M = Seismic Construction (Non-Certified)
N = California OSHPD Certification + Chicago
P = Shake Table Cert. (ASCE 7-05/ICC-ES AC 156)
+ Chicago
Q = Seismic Construction (Non-Certified) + Chicago
0 = Standard
Feature 20: CRATING
A = Export Crating
B = Export Crating - No Condenser Section
0 = Standard - None
Feature 21: WATER-COOLED
CONDENSER
A = Balancing Valves
B = Water Flow Switch
C = Motorized Shut-off Valve
D = Head Pressure Control
E = Options A + B
F = Options A + C
G = Options A + D
H = Options B + C
J = Options B + D
L = Options A + B + C
M = Options A + B + D
R = SMO 254 Brazed Plate Heat Exchanger
S = Options A + R
T = Options B + R
U = Options C + R
V = Options D + R
W = Options A + B + R
Y = Options A + C + R
Z = Options A + D + R
1 = Options B + C + R
2 = Options B + D + R
3 = Options C + D + R
4 = Options A + B + C + R
5 = Options A + B + D + R
0 = None
Feature 22: CONTROL VENDORS
A = WattMaster Orion VCM-X Controls System
B = JENEsys Control System with Web UI
C = WattMaster Orion VCM-X Controls System with
Specials
E = Remote Mounted AAON Mini Controller
F = JENEsys Control System with Web UI + Fox
G = JENEsys Control System with Web UI + Lon
H = JENEsys Control w/ Web UI + BACnet MSTP
J = JENEsys Control w/ Web UI + BACnet IP
K = JENEsys Control w/ Web UI + Modbus RTU
L = JENEsys Control w/ Web UI + Modbus TCP
T = WattMaster Orion VCB-X Controls System +
Integrated BACnet MSTP
U = WattMaster Orion VCB-X Controls System +
Integrated BACnet MSTP with Specials

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
