AAON RN Series Installation, Operation & Maintanance Manual

31
Be careful to install the provided neoprene
gasket according to the following figure
prior to setting the unit on the curb.
Where the supply or warm air duct
passes through a combustible roof, a
clearance of 1 inch must be
maintained between the outside
edges of the duct and combustible
material in accordance with National
Fire Protection Association Standard
No. 90A. Provide flashings or
enclosure between structure and roof
and all joints
must be sealed with
mastic roofing to ensure a watertight
seal.
CAUTION
All roofing work should be performed
by competent roofing contractors to
avoid any possible leakage.
CAUTION

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
