RSMD-CM Technical Guide
LCD SCREENS
Module Screens
Module Screens
Refer to the following map when navigating through the
RSMD-CM Screens. From the RSMD-CM Screen, press
<ENTER> to scroll through the screens.
RSMD
1067vxxx
EBUS COMM
PACKETS
E-BUS COMMUNICATION DIAGNOSTICS
Number of COMM packets received.
SOFTWARE
1067vXXX
CURRENT SOFTWARE VERSION
You can access the protected screens from this screen by holding
the <UP> button for ve seconds.
BOARD/EBUS
ADDRESS
CURRENT BOARD ADDRESS
#COMP
CONFIGURED
# OF COMPRESSORS CONFIGURED
#COND
CONFIGURED
# OF CONDENSERS CONFIGURED
COMP A1-B1
FIXED OR DIG
COMPRESSOR A1 or B1 - FIXED or DIGITAL
COMP A2-B2
FIXED OR DIG
COMPRESSOR A2 or B2 - FIXED or DIGITAL
