RSMD-CM Technical Guide
LCD SCREENS
System Status Screens
System Status Screens
Refer to the following map when navigating through the System
Status Screens. From the SYSTEM STATUS Screen, press
<ENTER> to scroll through the screens.
SYSTEM
STATUS
MODE OF
OPERATION
SYSTEM MODE OF OPERATION
Possible Choices are:
OFF, COOL, HEAT, DEHUMID, FORCE
COMP A1-B1
OFF/
MODULATING %
COMPRESSOR A1, B1
(based on board address)
OFF / MOD POSITION
OFF: Compressor is o󰀨.
MODULATING PERCENTAGE: 0-100%
COMP A2-B2
ON/OFF
COMPRESSOR A2, B2
(based on board address)
ON, OFF, FORCED
OFF: Compressor is o󰀨.
ON: Compressor is on.
COND 1 FAN
OFF/
MODULATING %
CONDENSER FAN 1
OFF / MOD POSITION
OFF: Condenser is o󰀨.
MODULATING PERCENTAGE: 0-100%
COND 2 FAN
OFF/
MODULATING %
CONDENSER FAN 2
OFF / MOD POSITION
OFF: Condenser is o󰀨.
MODULATING PERCENTAGE: 0-100%
BYPS VLV
CLOSED OR
% VALVE
WATERSIDE ECONOMIZER BYPASS VALVE
CLOSED or MOD POSITION
CLOSED: Valve is closed.
VALVE PERCENTAGE: 0-100%
DEFROST
# MINUTES
DEFROST INTERVAL TIMER
# of MINUTES
OR
If congured for Water Source Heat Pump
H2O FLOW
YES/NO
WATER FLOW
YES/NO
