90VCCX2 Controller Technical Guide

APPENDIX C: BACNET GUIDE

Enumerated Fields

VCCX CONTROL MODE = ENUMERATED

ITEM ENUM

Supply Air Cooling Only 0

Supply Air Tempering 1

Outdoor Temperature Control 2

Return Air Constant Volume Mode 3

Space Temp Constant Volume Mode 4

Space Temp w/ High OA Content 5

Single Zone VAV 6

Table 32: VCCX Control Mode = Enumerated

VCCX CONTROL STATUS = ENUMERATED

ITEM ENUM

Unoccupied 0

Occupied 1

Override Mode 2

Holiday Unoccupied 3

Holiday Occupied 4

Forced Occupied 5

Forced Unoccupied 6

Remote Contact Occupied 7

Reserved 8

Reserved 9

Reserved 10

OA Damper Calibration 11

Table 33: VCCX Control Status = Enumerated

VCCX HVAC MODE STATUS = ENUMERATED

ITEM ENUM

O󰀨 0

Vent Mode 1

Cooling Mode 2

Heating Mode 3

Vent RH Mode 4

Cooling RH Mode 5

Heating RH Mode 6

Warm Up Mode 7

Purge Mode 8

Defrost Mode 9

Cool Down Mode 10

Table 34: VCCX Mode Status = Enumerated
