Operating and display elements
Aastra 632d 17
eud-1586/1.0 – R3.0 – 04.2013
Key designations and sockets
Key Press In the state... Description
1 Loudspeaker
2 LED indicator 3 colours LED as per Table in chapter
"Indicator LED signals", page 34
3 Display TFT colour display
4 Side keys + / - short • Idle state
• In a connection
• Call up the phone number
• Adjusting the volume
Middle side key short all states Excute configured call number
long Idle state Configure side key
