1.2 REAR
11 Pitch and Mirror Shutter Adjusting Tools
12 CCD Led - On/Off indicator
13 Magnetic wheel for the magazine’s sprockets
14 XLR4 Connector allows for the battery connection
15 Aperture Opening
16 Battery Locking Screw
17 Magnetic Wheel for the magazine’s take-up core
18 LCD Control Panel displays AatonCode, ASA, speed, voltage, or remaining footage
19 Jog Wheel provides quick adjustment of ASA, speed, and phasing
20 Lemo5 Connector for AatonCode and SMPTE communication
13
GENERAL OVERVIEW
11
12
13
14
15
17
16
18
19
20
